High Speed Take up Winder for Fiber Glass Aramid Fiber
High Speed Take up Winder for Fiber glass Aramid fiber Application : manily used as in health, medicne, decoration, prot
Send your inquiryDESCRIPTION
Basic Info.
Model NO. | LY-300mm |
Automatic Grade | Semi-Automatic |
Inclusion Degree | Half Winding Machine |
Structure | Cantilevered Winding Machine |
Film Frame Structure | Mechanical Stretch |
Series | R Series - Cantilever Winding Machine |
Touch Screen | 10 Inch |
Tension Control | Dancer Arm/Air Cylinder |
Shaft Structure | Cantilever |
Machine Frame | 4~8 Spindles / Set |
Winding Ratio | Fix / Adjustable |
Power | AC220V/60Hz |
Winding Diameter | 290mm |
Traverse Length | 150/200/250mm |
Winding Speed | 10-200m/Min |
Material Width | 1-4mm |
Transport Package | Export Wooden Case |
Specification | customized |
Trademark | Lang Yu |
Origin | China |
HS Code | 84515 |
Production Capacity | 3000 Sets/Year |
Product Description
High Speed Take up Winder for Fiber glass Aramid fiberApplication : manily used as in health, medicne, decoration, protection, electronic packaging, textile and cable industry under the high-speed, high efficiency , and the high quality products will be available .The winding machine ahs advantages of novel design , high yield rate, uniform tension, operation is very simple, low energy comsumption.This machine could be used in high performance fiber, composite materials , wire and cable fiber, resistance water yarn , polyester wire wheel, aromatic polyamide yarn, glass basalt fiber, golden bracing wire , mice belt, materials , PTFE insulated tape, electronic belt and electron carier tape and other industries in the area use.
Technical Parameter
Drive | Frequency-Controlled |
Titer | 150 to 20000 Dtex |
Max winding speed | 300m/min |
Winding Ratio | Electronic |
Traverse Length | 100, 150, 200, 250mm or more |
Maxium Package diameter | 290mm |
Maximum Pacakage weight | 20kg |
Real photo of Machine
Finished Boobin show
Certificate
FAQ
Q:Are you manufacturer or trader?
A:We are manufactuer.
Q:Where is your factory location?
A:Our factory is located in Jiangyin city of China.
Q:Can you design or modify the machine according to my requirement?
A:Yes,we can design or modify the machine according to your requirement.
Q:What is your payment term?
A:30% deposit in advance, 70% balance before shipment or L/C at sight.
Q:What is the warranty for your machine?
A:Our machine warranty 12 month after installation. We also offer lifetime maintenance.
Q:Do you offer installation and training service for your machine?
A:Yes,we can offer installation and operator training.
